THE GO-ANYWHERE RIG
The satyr was a mythical forest creature known to the Romans as a woodland spirit (and a bit of a party animal). The embodiment of fun and rowdiness, the satyr was a man built atop the legs of a goat.
And climb like a goat the new Satyr does. It turns, handles and descends beautifully too, with geometry influenced by Tom Kellogg’s years of championship winning frame design mixed with his dirt riding passion and prowess.
The Satyr
Framesets starting at $2,675
Complete bikes starting at $4,250
Have a question about your build? We love hearing from you and guarantee we’ll call you back within 24 hours.
All bikes are built to order and arrive in 7 - 10 days from the time of purchase.
FRAME SPECIFICATIONS
The frame specifications below are the standard build specifications for the Satyr. Other options are available for custom builds so please contact us if you do not see what you're looking for below.
|
FRAME |
Satyr Gravel Disc - A custom blend of size specific, triple butted, TIG welded steel tubing with custom shaping for maximum tire clearance and ride quality |
| FORK | ENVE Adventure carbon fork |
| GROUPSET | Compatible with all 11sp and newer road disc groups (mechanical and electronic) |
| CRANK / CHAINRINGS | 1x 38t to 46t or 2x WIDE 43/30 up to 46/33 and 48/31 |
| CASSETTE | All standard 11sp and 12sp road or mountain cassettes |
| WHEELSET |
650B or 700C |
| TIRES | 650B: 47mm to 55mm/2.2" or 700C: 32mm to 50mm |
|
BRAKE TYPE |
Front Flat Mount - 140/160mm / Rear Flat Mount - 140mm/160mm |
|
FRONT AXLE |
Enve 12mm x 100mm included |
|
REAR AXLE |
Ritte premium 12mm x 142mm included |
| HANDLEBAR |
Compatible with any 1 1/8" stem / handlebar |
|
SEATPOST |
27.2mm round |
|
HEADSET |
Custom machined headtube for IS42/52 internal headsets |
|
BOTTOM BRACKET |
T47 - 68mm Threaded |
| CABLE ROUTING | Internal through downtube |
| WARRANTY | Limited lifetime warranty |
GEOMETRY
|
|
XS |
S |
M |
L |
XL |
XXL |
|
Seat tube (C-T) |
491 |
512 |
523 |
539 |
551 |
564 |
|
Head Tube |
95 |
115 |
130 |
145 |
160 |
175 |
|
Head Angle |
71 |
71.5 |
71.5 |
72 |
72 |
72.5 |
|
Top Tube |
525 |
540 |
555 |
565 |
578 |
592 |
|
Seat Angle |
74 |
73.5 |
73.5 |
73 |
72.5 |
72.5 |
|
Stack |
530 |
547 |
559 |
577 |
588 |
604 |
|
Reach |
372 |
376 |
388 |
388 |
392 |
401 |
|
Wheelbase |
1011 |
1018 |
1035 |
1029 |
1039 |
1049 |
|
BB Drop |
80 |
80 |
78 |
78 |
74 |
74 |
|
RC |
435 |
435 |
435 |
435 |
435 |
435 |
|
Fork Rake |
55 |
55 |
55 |
49 |
49 |
49 |
If you have any concern about fit or sizing please email us at support@ritteracing.com and we would be glad to make sure you get the best fitting bike possible.
FAQs
WHY STEEL?
When riding off-road, we want as smooth a ride as possible without resorting to proprietary suspension components or bits that will make your bike disposable. Steel is a no-brainer answer for us - we get the stiffness and acceleration we want, and the ride quality so lauded of the material.
Plus, steel is durable and resilient. These bikes can take a beating and get you home safely. It’s the ideal material for a bike subjected to rough riding.
WHAT DOES IT WEIGH?
Frames weigh around 2200g. Complete builds are generally between 19-22lbs depending on your build. Big tires add weight, of course. Compare this with other steel frames of the same tire clearance, and the Satyr is about a pound lighter.
WHAT IS THE REASON BEHIND THE OFFSET CHAINSTAY?
Great question - clearance. The offset chainstay allows greater tire clearance and greater drivetrain compatibility. The Satyr can take a 650x2.2” tire with gravel 2x like Shimano’s GRX or SRAM’s AXS WIDE, along with all standard 1x configurations. The Satyr is designed to take you almost anywhere - and that means groupset and tire compatibility has to be great.
You’ll notice that we’re using a full-length tubular chainstay rather than a metal plate or yoke - this is a key reason we’re able to keep the frameset weight so comparatively low.
General Ritte FAQs can be found here
“THERE’S NO OTHER WAY TO SAY IT – IT’S JUST A LOT OF FUN TO RIDE. THE SATYR FEELS BEAUTIFULLY PLANTED AND STABLE, ABLY ASSISTED BY THE SPRINGINESS OF THE REYNOLDS 725 TUBING. IT HAS THE UNMISTAKABLE FEEL OF HIGH-END CUSTOM STEEL, BUT WITHOUT SLAPPING ON THE ASSOCIATED PRICETAG. ”
The Satyr clears up to a 700c x 50mm or a 650b x 2.2" tires to tackle tough terrain.
Fender ready - mounting points front and rear
Differing tube diameters & tube wall thicknesses selected for each frame size to deliver tuned ride characteristics across the full range
TAKE A RIDE ON THE WILD SIDE
The Satyr’s custom blend steel tubeset is stiff where you need it, but tames the trail chatter in a manner that only steel can accomplish. Featuring size-specific wall thicknesses, tube diameters, and butting profiles specially selected and blended.
- Versatile build options - 1x or 2x, mechanical or electronic, 11sp, 12sp, or even 13sp
- Up to 700c x 50mm or 650b x 2.2" tire clearance
- Mounts for fenders, cargo, and three bottles
EXPLORE THE UNKNOWN
The Satyr belongs on the wild side of your drop bar stable, just begging you to turn every ride into a party. Egging you on - “slide into that corner,” “jump those roots,” “send it down that chute.” A bike for pure fun - the Satyr truly dials it up to 11.
- Full internal cable routing
- Fitted with the Enve Adventure Fork
- Also available in titanium
The Satyr belongs on the wild side of your drop bar stable, just begging you to turn every ride into a party. Egging you on - “slide into that corner,” “jump those roots,” “send it down that chute.” A bike for pure fun - the Satyr truly dials it up to 11.
• Full internal cable routing
• Fitted with the Enve Adventure Fork
• Also available in titanium
