Elegant, silky, potent - the most desirable of human characteristics, now distilled into a machine. Welcome to our most capable road bike, your most capable road bike.
The Phantom is our new All-Road bike. It’s got race pedigree in a package built out of custom specified Reynolds 725 tubing and designed by UCI World Championship winning frame builder Tom Kellogg. Aggressive does not need to mean harsh - we wanted a bike that smooths out the road in a way that only a silken Phantom could without losing the tenacity of a true road machine. This unique combination of geometry, tubing, and clearance for 32c tires ensure this is the first bike you reach for on any adventure.
Further outfitted with a T47 bottom bracket shell that allows room for entirely internal cable routing, flat mount disc brakes, and 12mm thru axles the Phantom accelerates and brakes with a potency admired by any racer. We dressed this two wheeled apparition in a paint scheme befitting of it’s elegance, so as not to overly intimidate any of its stablemates.
For the first time, the new Ritte Phantom is available as a complete bike or a frameset. We’ve got three stock build packages to choose from - with your choice of gearing and cockpit sizes. Available to be configured immediately in the bicycle builder on Ritte.cc.
But don’t think you cant put your own spin on things - we know that any rider exuding enough class to own one of these Phantoms is going to be a person of great brilliance and creativity. For that reason, we are proud to offer completely custom builds and paintwork. Our wrenches and paint booth are ready to create to your specifications.
The only thing these bikes can’t do, yet, is ride themselves. We’ll leave the Fun and Glory to you.
Shipping the second week of January.
The frameset includes frame, fork, seat collar, thru-axles, and all guides/plugs/grommets etc for any type of build (electronic or mech).
Component | Shimano R7000 105 | Shimano R8000 Ultegra | SRAM RED eTap AXS w/ Enve | Custom |
Groupset | Shimano R7020 Mechanical Shifting w/ Hydraulic Disc Brakes | Shimano R8020 Mechanical Shifting w/ Hydraulic Disc Brakes | SRAM RED eTap AXS HRD 12sp. Wireless Electronic Shifting w/ Hydraulic Brakes | Email us at support@RitteRacing.com and we would be honored to build your dream spec! |
Wheelset | Hunt Aero Light Disc Wheels | Hunt Aero Light Disc Wheels | Enve 3.4AR or 4.5AR Wheels | |
Bar/Stem/Seatpost | FSA Alloy (in rider selected lengths/widths) | FSA Energy Alloy (in rider selected lengths/widths) | Enve Carbon Road Stem, Enve Carbon Road Handlebar, Enve Carbon Seatpost | |
Saddle | Fabric Scoop | Fabric Scoop | Fabric Scoop | |
Tires | Michelin Power All Season | Schwalbe Pro One TLE 28c | Schwalbe Pro One TLE 28c | |
Headset | Cane Creek | Cane Creek | Cane Creek 110 | |
Note: | Riders may choose their gearing, crank lengths, stem lengths, and bar widths on all builds |
Size | ST(C-T) | Head Tube | Head Angle | Top Tube | Seat Angle | Stack | Reach | Wheelbase | Front Center | BB Drop | Rear Center | Fork rake |
XS | 499 | 115 | 72 | 525 | 74 | 523 | 374 | 991 | 577 | 76 | 425 | 50 |
S | 518 | 135 | 72.5 | 539 | 73.5 | 541 | 378 | 991 | 583 | 74 | 420 | 50 |
M | 536 | 150 | 73 | 554 | 73.5 | 559 | 388 | 990 | 586 | 74 | 415 | 43 |
L | 548 | 165 | 73.5 | 565 | 73 | 573 | 390 | 992 | 588 | 72 | 415 | 43 |
XL | 565 | 180 | 73.5 | 577 | 73 | 588 | 398 | 1004 | 600 | 72 | 415 | 43 |
XXL | 582 | 200 | 73.5 | 593 | 72.75 | 605 | 406 | 1023 | 613 | 70 | 420 | 43 |
Frame Size | Height Range* |
XS | 5’0” - 5’4” (152 - 162CM) |
S | 5’3” - 5’8” (160 - 172CM) |
M | 5’6” - 5’10” (168 - 178CM) |
L | 5’9” - 6’2” (175 - 188CM) |
XL | 6’0” - 6’4” (183 - 193CM) |
XXL | 6’3”+ (190CM+) |
*This is a rough guide, and we recognize that everyone is different. If you have any concern about fit or sizing please email us at support@ritteracing.com and we would be glad to make sure you get the best fitting bike possible.
